2x60 Assay Bin

Magnetic base for organizing two columns of 4 stackers

  • DOES NOT SUPPORT BINS, BINS REQUIRE a 1x3 70mm Base

Overview

  • Internal Dimensions: 60mm × 120mm × 20mm
  • External Dimensions: 65mm × 125mm × 25mm
  • Primary Use: Storing assay cards, certificates, and small documents
  • Capacity: Holds approximately 10-15 standard assay cards
  • Material: Durable PLA+ or PETG
  • Color Options: Clear, Black, or Custom
Table of contents
  1. 2x60 Assay Bin
    1. Features
    2. Compatible Contents
    3. Technical Specifications
    4. Printing Recommendations
    5. Assembly
    6. Maintenance

Features

  • Secure Lid: Snug-fitting lid to protect contents
  • Stackable Design: Interlocking design for secure stacking
  • Label Area: Flat surface for labeling or barcode
  • NFC Ready: Optional NFC tag integration for digital tracking

Compatible Contents

  • Standard assay cards (various sizes)
  • Small certificates of authenticity
  • Small paper documentation
  • Small collectible cards

Technical Specifications

  • Wall Thickness: 2.5mm
  • Base Thickness: 3.0mm
  • Lid Type: Snap-fit
  • Weight: ~50g (empty)

Printing Recommendations

  • Layer Height: 0.2mm
  • Infill: 20% (30% for added strength)
  • Supports: Not required
  • Print Orientation: Print base and lid separately on flat side

Assembly

  1. Print the base and lid separately
  2. Ensure the lid fits snugly on the base
  3. For NFC functionality, insert the NFC tag in the designated slot
  4. Use the label area for identification if needed

Maintenance

  • Clean with a soft, dry cloth
  • Avoid harsh chemicals
  • Store in a cool, dry place
